38
Varyscan
®
4 1200 HMI
shutter open DMX 244 - 255
channel 6 = iris
iris (linear) DMX 000 - 255
channel 7 = rotating gobos (positioning and
rotation
0° DMX 000
180° DMX 063
360° DMX 126
540° DMX 191
rotation left (fast) DMX 192
rotation left (slow) DMX 222
rotation stop DMX 223 - 224
rotation right (slow) DMX 225
rotation right (fast) DMX 255
channel 8 = effect wheel
open DMX 000 - 031
artificial light filter DMX 032 - 063
daylight filter DMX 064 - 095
prism DMX 096 - 127
floodfilter DMX 128 - 159
infinitely variable from flood to open DMX 160 - 255
2. 6 channels (Clay Paky Goldenscan 3 compatible)
channel 1 iris and gobo rotation
channel 2 colour
channel 3 gobo and effect wheel
channel 4 dimmer / shutter
channel 5 X-axis
channel 6 Y-axis
channel 1 = iris and gobo rotation
iris cl osed / gobo first position DMX 0
iris open / gobo first position DMX - 64
second gobo position DMX 65
third gobo position DMX 66
..........
locked into position 360° DMX 191
locked into position 540° DMX 191
rotation left highest speed DMX 192
rotation left lowest speed DMX 222
rotation stop DMX 223 - 224
rotation right lowest speed DMX 225
rotation right highest speed DMX 255
channel 2 = colour
colour 0 (white) DMX 000 - 007
colour 1 DMX 008 - 015
colour 2 DMX 016 - 023
colour 3 DMX 024 - 031
colour 4 DMX 032 - 039
colour 5 DMX 040 - 047
