Back view and position of operating sections
Occupation of DMX-sockets
DMX-in
DMX-out
Pin No.
signal Colour of wire Pin No. Signal Colour of wire
1 Ground black 1 Ground black
2 DMX - white 2 DMX - white
3 DMX + red 3 DMX + red
4 free 4 not connected
5 +5V green/black 5 not connected
Unpacking of the Varyscan ® Equipment
The box contains:
Varyscan ® 1200 HMI
operating instructions
Check, if the delivery contains all parts.
Should you notice a damage through transportation, please inform immediately the carriers respectively your dealer. Also
in case of noticing missing parts.
