39
Varyscan
®
4 1200 HMI
colour 6 DMX 048 - 055
colour 7 DMX 056 - 063
colour 8 DMX 064 - 071
colour 9 DMX 072 - 079
colour 10 DMX 080 - 087
colour 11 DMX 088 - 095
colour 12 DMX 096 - 103
colour 13 DMX 104 - 111
colour 14 DMX 112 - 119
colour 15 DMX 120 - 127
colour wheel rotation speed (slow) DMX 128 -
colour wheel rotation speed (fast) DMX 255
channel 3 = gobo and effect wheel
white DMX 0 - 9
artificial light filter DMX 10 - 19
daylight filter DMX 20 - 29
prism DMX 30 - 39
floodfilter DMX 40 - 51
gobo 1 white DMX 52 - 64
gobo 1 artificial light filter DMX 65 - 77
gobo 1 daylight filter DMX 78 - 90
gobo 1 prism DMX 91 - 103
gobo 2 white DMX 104 - 116
gobo 2 artificial light filter DMX 117 - 129
gobo 2 daylight filter DMX 130 - 142
gobo 2 prism DMX 143 - 155
gobo 3 white DMX 156 - 168
gobo 3 artificial light filter DMX 169 - 181
gobo 3 daylight filter DMX 182 - 194
gobo 3 prism DMX 195 - 207
gobo 4 white DMX 208 - 220
gobo 4 artificial light filter DMX 221 - 233
gobo 4 daylight filter DMX 234 - 246
gobo 4 prism DMX 247 - 255
if at DIP-switch No. 2 switch is "ON"
GOBO 4 prism DMX 247 - 254
Reset DMX 255
channel 4 = dimmer / shutter
dimmer shutter closed --> blackout (BO) DMX 0
dimmer: you can perceive some light DMX 19
dimmer DMX 20 - 127
dimmer completely open DMX 128 - 137
shutter immediatelly closed DMX 138 - 139
shutter sequence 1 flash/sec upto 10 flashes/sec DMX 140 - 243
shutter open DMX 244 - 255
channel 5 = x (pan) 170°
channel 6 = y (tilt) 90°
3. JB lighting 6 channels
channel 1 X-axis
channel 2 Y-axis
