Varyscan
®
4 1200 HMI
Occupation of channels for Varyscan
®
4 1200 HMI
1. JB lighting 8 channels
Channel 1
X-movement
Channel 2
Y-movment
Channel 3
gobo
Channel 4
shutter / dimmer
Channel 5
color
Channel 6
Iris
Channel 7
rotating gobos (positioning and rotating)
Channel 8
effect wheel
channel 1 = x (pan) 170°
channel 2 = y (tilt) 90°
channel 3 = gobo
gobo 0 (Beam)
DMX
000 -
031
gobo 1
DMX
032 -
063
gobo 2
DMX
064 -
095
gobo 3
DMX
096 -
127
gobo 4
DMX
128 -
255
if at DIP-switch No.2 switch 4 is "ON"
gobo 4
DMX
128
-
254
Reset
DMX
255
channel 4 = colour
colour 0 (white)
DMX
000 -
007
colour 1
DMX
008 -
015
colour 2
DMX
016 -
023
colour 3
DMX
024 -
031
colour 4
DMX
032 -
039
colour 5
DMX
040 -
047
colour 6
DMX
048 -
055
colour 7
DMX
056 -
063
colour 8
DMX
064 -
071
colour 9
DMX
072 -
079
colour 10
DMX
080 -
087
colour 11
DMX
088 -
095
colour 12
DMX
096 -
103
colour 13
DMX
104 -
111
colour 14
DMX
112 -
119
colour 15
DMX
120 -
127
colour wheel rotation speed 1 (slow)
DMX
128 -
colour wheel rotation speed 7 (fast)
DMX
255
channel 5 = dimmer / shutter
dimmer shutter closed --> blackout (BO)
DMX
0
dimmer: you can perceive some light
DMX
19
dimmer
DMX
20 -
127
dimmer completely open
DMX
128 -
137
shutter immediatelly closed
DMX
138 -
139
shutter sequence 1 flash/sec upto 10 flashes/sec
DMX
140 -
243
