47
Varyscan
®
4 1200 HMI
D1,D2
Bridge
U1
M68HC11F1FN
U2 Eprom 27C256
U3 AM26LS32 IC DMX-IN
U4 PAL22V10
U5 74HC245
U6 no.
U7 PBL3771 driver x-motor
U8 PBM3960
U9 PBL3771 driver y-motor
U10 PBM3960
U11 TCA3727 driver for goborotation
U12 74HC574
U13 74HC574
U14 74HC574
U15 TCA3727 driver for iris
U16 TCA3727 driver for gobowheel
U17 LM317
U18 TCA3727 driver for colour wheel
U19 TCA3727 driver for effect wheel
U20 74HC574
U21 74HC574
U22 74HC574
U23 TCA3727 driver for shutter motor 1
U24 74HC574
U25 74HC574
U26 TCA3727 driver for shutter motor 2
Y1
Quarz 16MHz
S1
SW DIP-10 DIP-switch No. 1
S2 SW DIP-4 DIP-switch No. 2
