trigger2( CLK := button2 );
IF trigger2.Q THEN
fbPanel2.bEnable := NOT fbPanel2.bEnable;
END_IF
fbPanel2( hFocus:= hFocus, bLED=>LED2 );
(* Panel 3 *)
trigger3( CLK := button3 );
IF trigger3.Q THEN
fbPanel3.bEnable := NOT fbPanel3.bEnable;
END_IF
fbPanel3( hFocus:= hFocus, bLED=>LED3 );
CP-Link 3 ADS-Schnittstelle
Der CP-Link 3 ADS-Server ist auf AMS Port 19300 erreichbar. Zur Zeit ist eine Funktion implementiert:
AdsWrite
SetHidFocus
IndexGroup: 0x10000
IndexOffset: IP Address in network byte order or 0 to clear HID-Focus
Possible ADS return values:
ADSERR_DEVICE_INVALID_STATE - CP-Link 3 Remote Port Enumerator returned that command was
not valid
ADSERR_DEVICE_NOT_FOUND - CP-Link 3 Remote Port Enumerator not installed
ADSERR_DEVICE_ERROR - CP-Link 3 Remote Port Enumerator returned an error
ADSERR_DEVICE_BUSY - HID-Focus was not set as another client has the focus
ADSERR_NOERR - HID-Focus was set to given client
