Status displays
G&D FIBREVision · 51
English
User module (FIBREVision-CON)
LED Status Bedeutung
K/M on Keyboard (PS/2 or USB) was found.
blinking No keyboard (PS/2 or USB) was found.
Main on The main power supply provides the necessary voltage.
off The switch for the power supply is turned off or the connection of the
device with the mains supply is not established. Check the connection of
the IEC cable.
Red. on The optional power pack is connected and provides the required voltage
(12 Volt).
off The optional power pack has not been (properly) connected.
Sys. on System ready for operation.
slow
blinking
Defective internal communication.
Restart the device.
blinking Activated setup mode.
fast
blinking
The temperature in the device exceeds the valid values.
cyclic
flashing
The firmware that has been transmitted to the device by the update
wizard is being tranmitted to all components of the system.
This process might take several minutes.
Trans. on The communication with the computer module has been successfully
established.
blinking The communication with the computer module could not be established.
Video on The incoming image signal at the video input of the computer module is
being properly received by the user module.
blinking No image data are being received at the computer module.
