Configuration
16 · G&D FIBREVision
Changing the configuration
The configuration can either be changed in the setup mode or in the setup menu.
The descriptions of the configurable functions on the following pages include
instructions on how to configure both the setup mode and the setup menu.
Operating the setup mode
The setup mode can be enabled using the console keyboard. After enabling, the con-
figuration of the FIBREVision system can be changed by using various step keys.
How to enable the setup mode:
 Press the Hotkey+Backspace (default: Ctrl+Backspace ) key combination to enable
the setup mode.
The successful activation of the setup mode is displayed by the blinking NUM ,  and
Scroll control LEDs on the keyboard. Additionally, the yellow User LED will blink at
both the computer module and the user module.
Now you can perform a setup function.
How to perform a setup function:
 After enabling the setup mode, press one of the setup keys described on the fol-
lowing pages.
How to end the setup mode without performing a function:
 Press ESC to end the setup mode.
NOTE: In addition to the configuration settings, further settings (see page 38 ff.)
enable the user to adjust special system features to the characteristics of the oper-
ating environment
NOTE: Only one setup function can be performed after the calling of the setup mode.
If you want to perform more functions, please restart the setup mode.
NOTE: The key combination for enabling the setup mode needs to be pressed for
seven seconds.
After the first call of the setup mode, the hotkey delay can be disabled by pressing
the setup key 8 (see page 19).
