The FIBRE-Power expansion
52 · G&D FIBREVision
The FIBRE-Power expansion
The FIBRE-Power expansion is provided for the variants FIBREVision-AR and -ARU
to control the ATX-Power and Reset buttons of the computer at the remote console.
Scope of delivery
The scope of delivery of the FIBRE-Power expansion includes the following items:
 G&D Power Card (slot card for installing in the computer)
 connection cable to connect G&D Power Card and computer module
 single-sided ready-made cable for connecting a panel to the user module
 2 x two-pin connection cable (0,4 metres)
 2 x two-pin extension cable (0,4 metres)
Functionality
The remote control of both ATX-Power and Reset function is carried out through a
panel with two buttons. The panel is installed at the remote console.
A four-pin modular socket on the back panel of the user module (FIBREVision-
CON) connects the panel to the system. The connection cable that is provided in the
scope of delivery has to be fixed to the panel (see Allocating the connection cable for the
panel on page 55).
NOTE: The panel to operate FIBRE-Power is not included in the scope of delivery
of FIBRE-Power and has to be assembled by an expert.
