Configuration
G&D FIBREVision · 23
English
Changing the scancode set of a PS/2 keyboard
If a key is pressed on the PS/2 keyboard, the keyboard processor sends a data packet
that is called scan code. The two common scan code sets (sets 2 and 3) contain dif-
ferent scan codes.
The FIBREVision system interprets all inputs of the PS/2 keyboard with scan code set 2.
If the pipe (“|”) cannot be entered or if the arrow keys of the keyboard do not work
as expected, it is recommended to switch to scan code set 3.
How to change the setting of the scancode set:
Setu
p mode
1. Press Hotkey+Backspace (default: Ctrl+Backspace ) to activate the setup
mode. If the hotkey delay is active, press the key combination for seven
seconds.
2. Press one of the setup keys listed below to activate a particular scancode set:
2  activates the scancode set 2 for PS/2 keyboard inputs
3  activates the scancode set 3 for PS/2 keyboard inputs
3. Restart the FIBREVision system. After the restart, the keyboard is initialised
and the selected scan code set does apply.
Setup menu
1. Use the terminal emulator to establish the connection to the FIBREVision
system.
2. Use the arrow keys to select the Scancode Set CPU row to change this setting
for the local console.
Use the arrow keys to select the Scancode Set CON row to change this setting
for the remote console.
3. Press the Space key (repeatedly) to activate a certain scancode set:
2  activates the scancode set 2 for PS/2 keyboard inputs
3  activates the scancode set 3 for PS/2 keyboard inputs
4. Press the S key to save the settings.
5. Restart the FIBREVision system. After the restart, the keyboard is initialised
and the selected scan code set does apply.
