12
Secure the handlebar with the prepared T-handle screw (9) (Fig. 4e).
Now secure the handlebar cover with the two previously removed screws
(13) (Fig. 4f).
note!
Again, be sure not to pinch the pulse cable!
4e
4f
Inserting the seat post and assembling the seat
Assembling the seat post and the seat requires seat post (23), seat (28),
the seat clamp (26), the seat adjusting screw (27) and the all-purpose
tool (Fig. 5a).
Slightly loosen the seat adjusting screw. Then place the seat post into the
base frame. Now pull the adjusting screw outward against the spring
resistance, and slide the seat tube back into the main body. Now release
the screw and check whether the bolts locked into one of the adjustment
holes by pulling and pushing the seat tube. Then securely tighten the
screw in order to remedy any play (Fig. 5b).
5a
5b
GB/IE
