4.5 Advanced Chipset Features
Phoenix – AwardBIOS CMOS Setup Utility
Advanced Chipset Features
DRAM Timing Selectable
[By SPD]
x CAS Latency Time
Auto
Item Help
x DRAM RAS# to CAS# Delay
Auto
x DRAM RAS# Precharge
Auto
x Precharge delay (tRAS)
Auto
x System Memory Frequency
Auto
SLP_S4# Assertion Widtch
[4 to 5 Sec.]
System BIOS Cacheable
[Enabled]
Video BIOS Cacheable
[Disabled]
Memory Hole At 15M-16M
[Disabled]
► PCI Express Root Port Func
[Press Enter]
** VGA Setting **
PEG/Onchip VGA Control
[Auto]
On-Chip Frame Buffer Size
[ 8MB]
DVMT Mode
[DVMT]
DVMT/FIXED Memory Size
[ 128MB]
Boot Display
[Auto]
Panel Scaling
[Auto]
Panel Number
[ 640x480]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü DRAM Timing Selectable
Optionen: By SPD / Manual
ü CAS Latency Time
Optionen: 5 / 4 / 3 / 6 / Auto
ü DRAM RAS# to CAS# Delay
Optionen: 2 / 3 / 4 / 5 / 6 / Auto
ü DRAM RAS# Precharge
Optionen: 2 / 3 / 4 / 5 / 6 / Auto
ü Precharge delay (tRAS)
Optionen: Auto / 4 / 5 / 6 / 7 / 8 / 10 / 11 / 12 / 13 / 14 / 15
ü System Memory Frequency
Optionen: Auto / 533MHz / 667MHz
ü SLP_S4# Assertion Width
Optionen: 4 to 5 Sec. / 3 to 4 Sec. / 2 to 3 Sec. / 1 to 2 Sec.
ü System BIOS Cacheable
Optionen: Enabled / Disabled
ü Video BIOS Cacheable
Optionen: Enabled / Disabled
ü Memory Hole At 15M-16M
Optionen: Enabled / Disabled
ü PCI Express Root Port Func
Untermenü: siehe "PCI Express Root Port Function" (p. 52)
ü PEG/Onchip VGA Control
Optionen: Onchip VGA / PEG Port / Auto
