Kapitel: BIOS-Einstellungen
Integrated Peripherals
Seite 56
Beckhoff New Automation Technology CB2051
4.6.3 SuperIO Devices
Phoenix – AwardBIOS CMOS Setup Utility
SuperIO Device
Onboard FDC Controller
[Enabled]
Onboard Serial Port 1
[3F8/IRQ4]
Item Help
Onboard Serial Port 2
[2F8/IRQ3]
UART Mode Select
[Normal]
x RxD , TxD Active
Hi,Lo
x IR Transmission Delay
Enabled
x UR2 Duplex Mode
Half
x Use IR Pins
RxD2,TxD2
Onboard Parallel Port
[378/IRQ7]
Parallel Port Mode
[Normal]
x EPP Mode Select
EPP1.9
x ECP Mode Use DMA
3
Onboard Serial Port 3
[3E8/IRQ11]
Onboard Serial Port 4
[2E8/IRQ10]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
ü Onboard FDC Controller
Optionen: Enabled / Disabled
ü Onboard Serial Port 1
Optionen: Disabled / 3F8/IRQ4 / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Auto
ü Onboard Serial Port 2
Optionen: Disabled / 3F8/IRQ4 / 2F8/IRQ3 / 3E8/IRQ4 / 2E8/IRQ3 / Auto
ü UART Mode Select
Optionen: IrDA / ASKIR / Normal
ü RxD , TxD Active
Optionen: Hi,Hi / Hi,Lo / Lo,Hi / Lo,Lo
ü IR Transmission Delay
Optionen: Enabled / Disabled
ü UR2 Duplex Mode
Optionen: Full / Half
ü Use IR Pins
Optionen: RxD2,TxD2 / IR-Rx2Tx2
ü Onboard Parallel Port
Optionen: Disabled / 378/IRQ7 / 278/IRQ5 / 3BC/IRQ7
ü Parallel Port Mode
Optionen: SPP / EPP / ECP / ECP+EPP / Normal
ü EPP Mode Select
Optionen: EPP1.9 / EPP1.7
ü ECP Mode Use DMA
Optionen: 1 / 3
