Benutzerhandbuch ACCESS-SYSTEM
KLING & FREITAG GMBH ©1995-2009 Version 6.0, 16.06.2009 Seite 20 von 60
5.3 ACCESS B5 Anschlussbelegung
Connector:
Speakon NL 4 MPR
1+ / 1-
Speaker B
-
Speaker A
Speaker A
+
Speaker B
1- 2-
1+
2+
IN
Mit Option 'EP-5 statt Speakon':
Connector:
Ep-5
Parallel to out
- Speaker B
- Speaker A
+ Speaker A
+ Speaker B
4
5
3
2
1
5.4 ACCESS B10 Anschlussbelegung
Connector:
Speakon NL 4 MPR
1+ / 1-
Speaker B
-
Speaker A
Speaker A
+
Speaker B
1- 2-
1+
2+
IN
Mit Option 'EP-5 statt Speakon':
Connector:
Ep-5
Parallel to out
- Speaker B
- Speaker A
+ Speaker A
+ Speaker B
4
5
3
2
1
Speaker B
Speaker A
Speaker B
Speaker A
