Assembling in the Door frame
WArnInG! Make sure you use the correct assembly materials.
the assembly materials enclosed with this article are suitable for atta-
ching the door bars to stable concrete walls. for attaching to lightweight
concrete walls, please contact your local dealer and enquire as to the
best method of attachment.
Attach the safety brackets directly above the
door frame on the back of the respective door.
(see Fig. 3)
After you have mounted the safety bracket you can mount the door bars into the door
frame as shown. (see Fig. 4)
First of all, hang the bar D into the safety bracket. Then press the ends of bar A against
the foremost door frames. (see Fig. 5)
Warning!
Make sure that the bar D is securely hung into the safety bracket.
Now check the article for stability by pulling and shaking it.
Fig. 5
A
A
Fig. 3
H
Fig. 4
c
I
D
Fig. 2
I
