Guntermann & Drunck GmbH CATCenter Installation Guide
Page 38
5.2 CATCenter X4
Workstation ports per device 4
Workstation ports max. per cluster 32
Transmission type to workstation module dedicated CAT-x link
Target ports 32
Target ports Cascade level 1 256
Target ports Cascade level 2 2048
Transmission type to target module dedicated CAT-x link
Update process local service socket
Network connection no
Power supply Main Type internal power pack
Connection IEC connector (IEC-320 C14)
Voltage AC100-240V/60-50Hz 180 - 110 mA
Redundant Type external power pack
(optional) Connection miniDIN-4 Power-Buchse
Voltage +12VDC/2,3A
Casing Material anodised aluminium
Dimensions Desktop 435 x 44 x 286 mm (W x H x D)
Rackmount 19” x 1HU x 286 mm (W x H x D)
Weight approx. 3.0 kg
Operating Temperature +5 to +45 °C
environment Air humidity < 80%, not-condensing
Interfaces to workstation module RJ45 socket
to target module RJ45 socket
for update 2.5 mm jack
for power switch RJ11 socket
Conformity CE, RoHs
