Guntermann & Drunck GmbH

CATCenter Installation Guide

Page 44

5.8

UCON-IP

Signal type/video

analogue

video

Video resolution

locale connection 1920 x 1440 @ 75 Hz

(depending on cable)

via IP native 1280 x 1024 @ 75 Hz

Transmission length
Workstation module to target module

300 m

Transmission type to workstation module

dedicated CAT-x link

Transmission type to KVM-IP client

TCP/IP protocol

Communication

Ethernet 10/100 Mbit/s or ISDN

Workstations

2 (1 x IP; 1 x local; concurrent)

Delay compensation

no

Update process

via network

Assigned workstation connections at
central module

1

Power supply

Main

Type internal power jack

Connection IEC connector (IEC-320 C14)

Voltage

AC100-240V/60-50Hz 0.5- 0.3A

Redundant

Type external power pack

(optional)

Connection miniDIN-4 power socket

Voltage

+12VDC/2.3A

Casing

Material

anodised

aluminium

Dimensions

Desktop 435 x 44 x 211 mm (W x H x D)

Rackmount

19” x 1HU x 211 mm (W x H x D)

Weight

approx. 3.5 kg

Operating

Temperature

+5 to +40 °C

environment

Air humidity

< 80%, not-condensing

Interfaces

for workstation

SubHD15 socket (Video)

2 x PS/2 socket (Keyboard/Mouse)

to central module

RJ45 socket

for network

2 x RJ45 socket

for ISDN

RJ11 socket

for update

via network port

Conformity

CE,

RoHs
