Guntermann & Drunck GmbH CATCenter Installation Guide
Page 46
5.10 CATpro2-VT100
Signal type/video serial, VT100
No. of interfaces to central module 1
Total length incl. cable 2.0 m
Transmission rate (RS232) max. 115200 bps
Power supply Main Type external power supply
Connection miniDIN-4 power socket
Voltage +12VDC
Casing Material anodised aluminium
Dimensions 105 x 26 x84 mm (W x H x D)
Design Converter
Weight approx. 200 g
Operating Temperature +5 to +45 °C
environment Air humidity < 80%, not-condensing
Interfaces
to target
SubD9 socket
Interfaces
to central module
RJ45 jack
Conformity CE, RoHs
