Guntermann & Drunck GmbH CATCenter Installation Guide
Page 40
5.4 UCON-a
Signal type/video analogue video
Video resolution
(depending on cable)
locale connection 1920 x 1440 @ 75 Hz
Transmission length
Workstation module to target module
100 m
Transmission type to workstation module dedicated CAT-x link
Workstations 1
Delay compensation no
Update process local service socket
Assigned workstation connections at
central module
1
Additional connectable
Workstation computer
0
Power supply Main Type internal power jack
Connection IEC connector (IEC-320 C14)
Voltage AC100-240V/60-50Hz 130 - 70 mA
Redundant Type external power pack
(optional) Connection 2 pole hollow socket
Voltage +5VDC/1,3A
Casing Material anodised aluminium
Dimensions Desktop 210 x 44 x 211 mm (W x H x D)
Rackmount 19” x 1HU x 211 mm (W x H x D)
Weight approx. 1.1 kg
Operating Temperature +5 to +45 °C
environment Air humidity < 80%, not-condensing
Interfaces for workstation SubHD15 socket (Vdeo)
2 x PS/2 socket (Keyboard/Mouse)
to central module RJ45 socket
for update 2,5 mm jack
Conformity CE, RoHs
