Seite 120: Empfohlene ersatzteile
ERSATZTEILELISTE
9
6-20
HySpeed HT2000LHF
Betriebsanleitung
Empfohlene Ersatzteile
Stromquelle
Teilenummer
Beschreibung
bestimmt für
Menge
Seiten bezug
027080
Fan: 225CFM 120VAC 50/60 Hz
M2,M3
1
6-2
027079
Fan: 450-550 CFM 120VAC 50/60 Hz
M4
1
6-2
041764
PCB Assy: HT2000LHF Control
PCB2
1
6-2
041246
PCB Assy: Relay, HD1070/HT2000
PCB4
1
6-2
005121
Pushbutton: 2 NO Green Illumin
PB1/LT1
1
6-3
005122
Pushbutton: 2 NC Red Extended
PB2
1
6-3
005149
Bulb: 120VAC
LT2
2
6-3
041294
PCB Assy: HT2000 THC Mother
PCB9
1
6-3
041186
PCB Assy: HT2000 THC
PCB10
1
6-3
003138
Circuit Breaker, 2 Pole, 600V 100A
CB1
1
6-4
003139
Contactor: 90A 3 Pole, 120VAC
CON1
2
6-4
041534
PCB Assy: Power Distribution
PCB1
1
6-4
005102
Thermostat: 160°C, 6 Amp
TS1
1
6-5
008317
Fuse: Semiconductor 125A, 250V
F1,F2
5
6-5
005227
Switch, Pressure 12 psi
PS3
1
6-5
006032
Solenoid Valve:150# 1/4 FPT 120V NC
SV6
1
6-5
006106
Solenoid Valve: 3-way 120VAC 1/8FPT
SV7
1
6-5
129118
CH130 Chopper SA
CH1,CH2
1
6-6
009684
Res: 4 Ohm 420W
R6A, R6B
1
6-7
003021
Relay, 120VAC NO SPST
CR1
1
6-7
009349
Coil Assembly: 200A HF
T4
1
6-7
009975
Cap: .1400pF 20kV
C4, C5, C6
3
6-7
004061
Electrode:Sprk Gap 1/8 x 1.6
3
6-7
129150
HV Transformer SA, 6kV
T3
1
6-7
029202
Current Sensor Assembly
CS1
1
6-7
129618
Switch, Level SA, 1/2 NPT
LS1
1
6-8
029323
Switch, Temp SA, 162 Deg. F
TS2
1
6-8
006046
Valve, Sol 240V 3/8 NPT NC
V1
1
6-8
128384
Kit: Pump, 70 GPH Positive Displace
1
6-8
029361
Flowswitch, 0.5 gpm
FS1
1
6-8
Gaskonsole
Teilenummer
Beschreibung
bestimmt für
Menge
Seiten bezug
005243
Pressure Switch:80psi
PS1,PS2
1
6-9
005149
Bulb, 120VAC
LT1
1
6-9
006109
Solenoid Valve: 150# 1/8FPT 120V 2-Way
SV1-3
1
6-9
006064
Needle Valve: 1/8 FPT .125 Orifice
MV1-MV4
1
6-9
011053
Flowmeter: 7.8 GPM/44CFH
FM1,FM2
1
6-9
011058
Flowtube with Float /BP-8 Flt:0-10 SC Cal 2%
2
6-9
011008
Shield: Plastic, for 011053 or 011056
2
6-9
011081
Flowmeter Float Stop
2
6-9
022020
Gauge: Pressure, 160 psi/bar, Panel Mnt
PG1-PG2
1
6-9
022008
Gauge, Press 100#/Bar 2.5" Dia.
PG3
1
6-9
