HPI Racing Cup Racer - Handbuch (Seite 48)

48
En
Parts # Qty Description
Parts List
6
Parts List
Ersatzteilliste
Pièces détachées
パーツリスト
6121 10 BODY PIN (SMALL)
6163 5 SERVO TAPE 20x100mm
6930 1 PINION GEAR 30 TOOTH (48 PITCH)
7209 1 DATSUN 510 BODY (WB225mm)
7210 1 DATSUN 240Z BODY (WB225mm)
7213 1 TOYOTA LEVIN AE86 BODY (WB225mm)
75106 20 BODY CLIP (6mm/BLACK)
75115 4 BALL STUD 4.3x10.3mm (2mm SOCKET)
75116 4 BALL STUD 4.3x13mm (2mm SOCKET)
85267 1 GEAR BOX SET A
85268 1 MOTOR MOUNT SET
85269 1 DIFFERENTIAL OUTDRIVE SET
85270 1 HUB CARRIER SET
85271 1 SPUR GEAR COVER SET
85273 1 BUSHING SET
85274 1 BUMPER SET
85275 1 BATTERY HOLDER SET
85276 1 BATTERY TRAY SET
85277 2 BODY MOUNTING SET
85278 1 SERVO/SHOCK TOWER/ROCKER MOUNTING SET
85279 2 FRONT BODY MOUNT/WHEEL HUB SET
85280 2 SUSPENSION ARM SET
85281 1 STEERING PARTS SET
85282 1 SHOCK PARTS SET
85283 4 SHOCK BODY
85284 1 GEAR BOX B/CHASSIS SPACER SET
85285 4 AXLE SHAFT
85298 6 METAL BUSHING 4x7x2.5mm
85527 1 BODY ACCESSORIES SET (CHROME)
85529 1 BODY ACCESSORIES SET (BLACK)
86014 1 GEAR DIFF BEVEL GEARS (13T and 10T)
86049 4 BALL STUD 4.3x8.8mm (2mm SOCKET)
86180 2 DIFF SHAFT 9.8x24.7mm
86189 1 CENTER DRIVE SHAFT 5.8x153mm (ORANGE)
86192 2 FIXING BALL 4.3x15mm
86194 1 SPUR GEAR HUB
86219 1 SPUR GEAR HUB NUT
86220 4 KING PIN BALL 7.8x4.8mm
86262 2 SUSPENSION SHAFT 2.5x22mm
86263 2 STEERING LINKAGE SHAFT 3x18mm
86264 2 SUSPENSION SHAFT 3x29mm
86265 4 SUSPENSION SHAFT 3x44mm
86273 2 SHOCK CAP 10mm (ORANGE)
86279 2 SHOCK SHAFT 2x28mm
86335 2 STEERING POST 4x27mm
86351 2 STEP SCREW 2.6X3x11mm
86392 2 DIFFERENTIAL SCREW M2x32mm
86849 2 STEERING ROD 4-40x53mm
86967 2 DRIVE SHAFT 6.2x32mm
86985 4 WHEEL WASHER (SILVER)
86991 2 SUSPENSION MOUNT A 38mm (ORANGE)
86992 1 SUSPENSION MOUNT B 38mm (ORANGE)
86998 1 BEVEL GEAR 16T
86999 1 BEVEL GEAR 39T (BALL DIFF)
87064 4 DIFFERENTIAL RING 13.8x21mm D-CUT
87065 4 BLADDER 9x3.5mm
87068 1 URETHANE BUMPER (GRAY)
87069 8 SILICONE O-RING P-2
87076 2 SHOCK SPRING 11x28x0.9mm 9COILS (COPPER)
87078 5 O-RING 5.0x1.0mm
87169 1 MAIN CHASSIS (FRP/2.0mm)
87185 1 UPPER DECK (FRP/2.0mm)
87274 2 STEERING PLATE A
87277 2 SHOCK SPRING 11x28x1.1mm 8COILS (GOLD)
87298 1 SPUR GEAR 65 TOOTH (DELRIN/48 PITCH)
87315 1 DIFFERENTIAL GEAR CASE SET (39T)
87591 1 GEAR DIFF ADJUST SPRING SET
87592 1 GEAR DIFFERENTIAL SET (39T)
87593 1 BALL DIFFERENTIAL SET (39T)
87594 1 SERVO SAVER SET
87595 2 SPORT SHOCK SET (42-55mm/10mm)
94036 10 BUTTON HEAD SCREW M2x5mm
94303 10 TP. FLAT HEAD SCREW M3x8mm (HEX SOCKET)
94304 10 TP. FLAT HEAD SCREW M3x10mm (HEX SOCKET)
94305 10 TP. FLAT HEAD SCREW M3x12mm (HEX SOCKET)
94353 10 TP. BUTTON HEAD SCREW M3x8mm (HEX SOCKET)
94354 10 TP. BUTTON HEAD SCREW M3x10mm (HEX SOCKET)
94355 10 TP. BUTTON HEAD SCREW M3x12mm (HEX SOCKET)
100628 2 MX60 SLICK TIRE M (60x26mm)
100629 2 MX60 T-DRIFT TIRE (60x25mm)
A046 4 O-RING P-3 (BLACK )
A150 12 BALL 2mm
A151 24 DIFFERENTIAL BALL (3/32) 2.4mm
A165 2 SPRING 6x7x1.5mm (DIFFERENTIAL) BLACK
A166 2 DIFF THRUST WASHER 2.2x6mm
B020 2 BALL BEARING 5x8x2.5mm
B028 2 BALL BEARING 6x10x3mm
B030 2 BALL BEARING 10x15x4mm
B068 6 METAL BUSHING 3x6x2.5mm
B096 2 BALL BEARING 5x9x3mm
Z082 10 FLAT HEAD SCREW M3x8mm (HEX SOCKET)
Z084 10 FLAT HEAD SCREW M3x12mm (HEX SOCKET)
Z086 10 FLAT HEAD SCREW M3x18mm (HEX SOCKET)
Z087 10 FLAT HEAD SCREW M3x20mm (HEX SOCKET)
Z090 10 FLAT HEAD SCREW M3x22mm (HEX SOCKET)
Z092 10 FLAT HEAD SCREW M3x24mm (HEX SOCKET)
Z115 10 E CLIP E-1.5
Z150 1 ANTENNA PIPE SET
Z155 1 DIFFERENTIAL LUBE (SILICONE)
Z157 1 MOLYBDENUM GREASE
Z164 1 HEAVY WEIGHT GREASE (#30000/GEAR DIFF)
Z186 1 PRO THREAD LOCK (RED/3cc)
Z203 10 WASHER M3x6mm
Z224 10 WASHER M3x8mm
Z242 20 E CLIP E2mm
Z264 10 PIN 2x10mm SILVER
Z340 25 WHEEL SCREW (HEX SOCKET)
Z341 10 CAP HEAD SCREW 4-40x14mm
Z352 10 BUTTON HEAD SCREW M3x8mm (HEX SOCKET)
Z356 10 BUTTON HEAD SCREW M3x18mm (HEX SOCKET)
Z419 10 CAP HEAD SCREW M2.6x35mm
Z420 12 CAP HEAD SCREW M2.6x6mm
Z422 12 CAP HEAD SCREW M2.6x10mm
Z424 10 CAP HEAD SCREW M2.6x16mm
Z452 10 TP. BUTTON HEAD SCREW M2x10mm
Z475 10 TP.FLAT HEAD SCREW M2.6x5mm
Z489 10 TP. FLANGED SCREW M2.6x10mm (HEX SOCKET)
Z525 10 FLAT HEAD SCREW M3x6mm
Z542 12 CAP HEAD SCREW M3x8mm
Z544 6 CAP HEAD SCREW M3x12mm
Z562 10 TP. FLANGED SCREW M3x10mm (HEX SOCKET)
Z661 4 LOCK NUT M2.6
Z662 4 LOCK NUT M2
Z676 4 LOCK NUT M3 THIN TYPE
Z685 10 WASHER 2.7x6.7x0.5mm
Z700 6 SET SCREW M3x3mm
Z705 6 SET SCREW M3x10mm
Z707 6 SET SCREW M3x15
Z725 6 SET SCREW M4x10mm
Z775 6 SET SCREW TP3.2x5mm
Z901 1 ALLEN WRENCH 1.5mm
Z903 1 ALLEN WRENCH 2.5mm
Z904 1 ALLEN WRENCH 2.0mm
Z950 1 CROSS WRENCH (SMALL)
Parts # Qty Description
