Jünger Audio-Studiotechnik GmbH
Seite
64
MIX4 Steckverbinder
connector :
RS232
female
9 pin Sub-D
1
RX+ RS422
2
TXD RS232
3
RXD RS232
4 NC
5 GND
6
RX- RS422
7 NC
8
TX- RS422
9
TX+ RS422
connector :
Remote
RJ45
1 CAN-H
2 CAN-L
3 GND
4 GND
5 GND
6 +5V
7 +5V
8 +5V
connector :
Ethernet
RJ45
1 Tx
(+)
2 Tx
(-)
3 Rx
(+)
4
5
6 Rx
(-)
7
8
connector :
GPI / TALLY
female
26 pin Sub-D
1 TALLY_1a
2 TALLY_2a
3 TALLY_3a
4 TALLY_4a
5 TALLY_5a
6 TALLY_6a
7 TALLY_7a
8 TALLY_8a
9
GND
10 TALLY_1b
11 TALLY_2b
12 TALLY_3b
13 TALLY_4b
14 TALLY_5b_6b
15 TALLY_7b_8b
16 GPI_1
(+)
17 GPI_1
(-)
18
+5V (110Ohm)
19 GPI_2
(+)
20 GPI_2
(-)
21 GPI_3_4
(+)
22 GPI_3
(-)
23 GPI_4
(-)
24 GPI_5_6
(+)
25 GPI_5
(-)
26 GPI_6
(-)
connector :
DCpower (opt.)
male 4
pin
XLR
1 GND
2 N.C.
3 N.C.
4
+9V to +36V
connector :
IF 2CH-MIC
female
25 pin Sub-D
1 MIC3
+
2 MIC3
GND
3
4
5
6
7
8
9
10
11
12 MIC4
-
13
14 MIC3
-
15
16
17
18
19
20
21
22
23
24 MIC4
+
25 MIC4
GND
connector :
AUX OUT
female 9-pin
Sub-D
1 AUX2-L+
2 GND
3 AUX2-R+
4 GND
5 AUX1-AES+
6 AUX2-L-
7 GND
8 AUX2-R-
9 AUX1-AES-
