Jünger Audio-Studiotechnik GmbH
Seite 66
MIX4 Elektrische Spezifikationen
Microphone inputs :
2x XLR
Transformer balanced 10k
Ω / phantom power 48V
Gain Digital gain (0 .... +70dB in 1dB steps)
Equivalent input noise
@ 200
Ω
-126dB (RMS) / +10dBu maximum mic input level
+22dBu maximum line input level
CMMR -95dB @ 50Hz / -85dB @ 15kHz
Sample Rate
44,1 / 48 kHz internal
32 - 48 kHz external
Propagation delay 2ms (digital I/O)
3ms (analog I/O)
Signal processing
32bit floating point
Line Inputs :
4 x 2 channel analogue
+22dBu @ 10k
Ω electronically balanced
CMRR –80dB @ 50Hz
4 x 2 channel digital AES/EBU 110
Ω balanced (or S/PDIF unbalanced)
with sample rate converter (SRC)
4 x 2 channel digital AES/EBU 110
Ω, balanced
Line outputs analogue :
4 x stereo-busses
+22dBu @ 0dBFS / 50
Ω - electronically balanced
2 x headphone +15dBu @ 0dBFS / 5
Ω
1 x monitor line out + 6dBu @ 0dBFS / 50
Ω
1 x AUX out +22dBu @ 0dBFS / 50
Ω
Line outputs digital :
2 x 4 x stereo busses
AES/EBU balanced 110
Ω
1 x AUX out AES/EBU balanced 110
Ω (channel status bits are only available in EXT AES
sync mode)
SD-SDI IN/OUT :
SMPTE 272M-A, C (625/50, 525/59,94), BNC, 75Ohm / 800mV +/- 5%
Equalization : 300m@270MHz (Belden 8281)
Audio : 20Bit, transparent for C- and U-Bits according to AES3
48kHz synchronous to video carrier
Latency : < 2,6ms
HD-SDI IN/OUT :
SMPTE 299M, BNC 75Ohm / 800mV +/- 10%
Equalization : [email protected] (Belden 1694A)
Audio : 20Bit, transparent for C- and U-Bits according to AES3
32 – 48kHz asynchronous to video carrier (HD)
Latency : HD <800µs, SD < 2.6ms
HD/SD auto detection (SMPTE 260M, 274M, 295M, 296M, 125M)
GPI / Tally :
6 GPI inputs
Optical coupler, driven by a current source 3V / 24V max.
8 Tally outputs Relay N.O. / 200V DC / 1A / 15W max.
Control-interfaces :
Ethernet 100Mbit/s
RJ45 - TCP/IP stack (device-server and router-client)
Serial interface 9-pin Sub-D - RS232 or RS422 (internal solder jumper)
MIX4 desktop-remote RJ-45 CAN-bus and external power (CAT5 cable) 10m standard
> 10m remote power supply necessary
Power :
100 – 230V AC / 35W
Optional 100 – 230V AC / 5V remote PS for cable length > 10m available
Optional DC input (9 – 36V) on XLR connector available on request
