Configuring »Dynamic Ports« « Central Module
17 · G&D DVICenter DP32
Showing Dynamic Port types
To facilitate the installation of the KVM system, the LEDs at the Dynamic Ports can
be switched into the special port mode.
In this mode, the Dynamic Ports to connect the target or the user modules are marked
by green and yellow blinking LEDs.
1. Click on KVM matrix systems > [Name] > DVICenter in the tree view.
2. Right-click the matrix switch, whose port type you want to show and click on
Dynamic Port LEDs > Show port type on the context menu.
3. Now the LEDs of the Dynamic Ports show the port mode:
4. To reset the standard port mode, right-click the matrix switch again and click on
Dynamic Port LEDs > Show status on the context menu.
User logout
Use the Logout button to exit the current session within the web application.
How to exit the current session within the web application:
1. Click the
Logout button (see figure on the right) to exit the current session
within the web application.
After your logout, the login box is displayed.
LED Port Type
yellow Shows connected user modules
green Shows connected target modules
NOTE: The Identification LEDs on the front and back panel of the device are
blinking while the port types are shown.
IMPORTANT: Always use the Logout function to exit your current session in order
to protect the web application against unauthorised access.
