Expanding switchable signals « Central module
23 · G&D DVICenter DP32
Adding or deleting module from a multichannel configuration
How to add modules to or deleting them from a multichannel configuration:
1. In the directory tree, click KVM matrix systems > [Name] > DVI-CONs or DVI-CPUs .
2. Right-click a user or computer module that is already assigned to a multichannel con-
figuration to which you want to add another module to or delete a module from.
3. On the context menu, click Multichannel configuration .
The display shows the current configuration. The left column ( Not assigned ) lists
the matrix switch modules you can add to the multichannel configuration.
4. Add more modules to or delete them from the multichannel configuration:
5. Click OK to save the new multichannel configuration.
NOTE: You can assign up to seven additional video channels and a USB or
RS232 channel to a computer’s or a console’s KVM channel.
Adding modules:  In the left column ( Unassigned ), click the module you
want to add. In the right column ( Assigned ) click the
channel to which you want to add the module to.
 Click (arrow right) to assign the module to the
chosen channel.
Deleting modules:  In the right column ( Assigned ), click the module you
want to delete from the multichannel configuration.
 Click (arrow left) to delete the module’s assign-
ment.
NOTE: The user and computer modules included in the multi channel configu-
ration are marked with a plus sign in the list of modules.
Click the plus sign to view the list of modules.
