31 · G&D DVICenter DP32
Installation
Connecting target computers
Keyb.: Use the purple plug of a Twin-PS/2 cable to connect the purple PS/2 socket
(keyboard) to this port.
Mouse: Use the green plug of a Twin-PS/2 cable to connect the green PS/2 socket
(mouse) of the computer to this port.
USB K/M: Use the USB device cable to connect one of the computer’s USB ports to this
port.
DVI-D CPU: Use the video cable to connect the digital video output of the computer to
this port.
Line In: Use an audio cable to connect the Line-Out interface of the computer to this port.
Line Out: Use an audio cable to connect the Line-In interface of the computer to this port.
Connection to the central module
Transmission: Use a category 5e (or better) twisted pair cable to connect the Transmis-
sion ports of the individual target modules to a Dynamic Port, which has been config-
ured for connecting a target module.
NOTE: Both keyboard and mouse signals can be transmitted to the computer using
the PS/2 or the USB ports.
NOTE: For more information, you can also refer to the instructions in the para-
graph Connecting target modules to the central module on page 7.
ADVICE: If the network fails or a port at the central module is not working, you can
establish a direct connection between a target and a user module.
Use a category 5e (or better) crossover cable to connect the modules.
