Central Module » Status displays
G&D DVICenter DP32 · 28
LEDs at the back panel
The back panel of the matrix switch provides an additional status LED at each RJ45
interface. The LEDs have the following function:
Interface LED Status Meaning
Network yellow lighting Active full duplex connection
blinking Active half duplex connection
green blinking Activity at the network port
Dynamic Port yellow on  Status mode:
A user is logged in at the user modules or accesses the
target module.
 Port mode:
The port is configured for connecting a user module.
off The port is not occupied.
green on  Status mode:
Connection to target or user module.
 Port mode:
The port is configured for connecting a target module.
off No connection to target or user module.
Ident. Ident. on LED to identify the device in the web application is active.
blinking Port type is shown at Dynamic Ports.
Power Red. on The redundant power pack is turned on and supplies the
required voltage.
off The redundant power pack is turned off or the connec-
tion to the mains could not be established.
Main on The main power pack is turned on and supplies the
required voltage.
off The main power pack is turned off or the connection to
the mains could not be established.
