43
SPECIALS
In the Specials configuration output and input words are transferred, depending on the resolution of the
encoders 16 bits or 32 bits.
The following functions can be carried out in addition to the class 2 functions:
- separation multi/singleturn position value
- running indication
- data exchange alarm
- limit switch function (minimum and maximum)
Configuration data:
- Special01
CLASS 2 – 32 bits: F1hex 2 input data words, 2 output data words for
preset value, data consistency
The following table gives an overview of the possible configurations of the encoders:
Encoder Positions/
revolutions
Distinguishable
revolutions
Total
resolutions
CLASS 1 CLASS 2 SPECIALS
RNX-13 Bit 8192 1 8192 ! ! -
RMX-25 Bit
)
8192 1 8192 ! ! -
