74
Table A.2: Measuring instrument-specific data class 2 (CLASS 2), optional functionality
In addition to table A.1
Function Octet no. Data type Name
Slave_Diag 17 octet string additional alarms
Slave_Diag 18, 19 octet string supported alarms
Slave_Diag 20, 21 octet string warnings
Slave_Diag 22, 23 octet string supported warnings
Slave_Diag 24, 25 octet string profile version
Slave_Diag 26, 27 octet string software version
Slave_Diag 28 - 31 32 bits without sign operating time
Slave_Diag 32 - 35 32 bits with sign offset value
Slave_Diag 36 - 39 32 bits with sign offset value of the manufacturer
Slave_Diag 40 - 43 32 bits without sign measuring units per revolution
Slave_Diag 44 - 47 32 bits without sign total measuring range in
measuring units
Slave_Diag 48 - 57 ASCII string serial number
Set_Prm 10 - 13 32 bits without sign measuring units per revolution
Set_Prm 14 - 17 32 bits without sign total measuring range in
measuring units
