57
3.4.4 Type of encoder
The type of encoder can be read in octet 10 of the diagnostic function. The type of encoder is defined in
hex code in the range from 0 to FF.
DDLM_Slave-Diag
Octet 10
Bit 0 - FF
type of encoder
Code Definition
00 absolute singleturn encoder
01 absolute multiturn encoder
02 absolute singleturn encoder with electronic revolution counter
03 incremental encoder
04 incremental encoder with battery buffer
05 incremental length measuring instrument
06 incremental length measuring instrument with battery buffer
07 absolute length measuring instrument
08 absolute length measuring instrument with periodic coding
09
• Not yet
•
used
•
FF
