The following figure gives an overview of the functions of the encoders:
Encoders according to encoder profile CLASS 1:
Position
Devices of class
1
basic functions
code sequence
transmission of the
position value
Encoders according to encoder profile CLASS 2:
Position
Devices of class
1
basic functions
code sequence
- - - - - - - - - - - absolute position
scaling function
- scaling function
- measuring units per revolution
- measuring range in measuring units
- control function/status
Devices of class
2
preset function
preset value
display of the position
value
