46
The parameters described in octets 9 an 26 are defined bit by bit as follows:
DDLM_Set_Prm
Octet 9
Bit 7 – 0
Data 2
7
- 2
0
operating parameters
Bit Definition = 0 = 1
0 Code sequence Clockwise (CW)
increasing position values
for clockwise rotation
(seen from the shaft) Counterclockwise (CCW)
increasing position values for
counterclockwise rotation
(seen from the shaft)
1 Class 2 functionality Disable Enable
2 Commissioning diagnostics No Yes
3 Scaling function control Disable scaling Enable scaling
scaling parameters are
adopted from octets 10 to 17.
4 Reserved for
... future
7 applications
DDLM_Set_Prm
Octet 26
Bit 7 – 0
Data 2
7
- 2
0
operating parameters (manufacturer-specific)
Bit Definition = 0 = 1
0 Limit switch function control Disable Enable
Scaling parameters are
adopted from octets 19 to 26.
1 Data_Exchange Alarm Disable Enable
2 Running indication Disable Enable
3 Multi/Single separation Disable Enable
4 Reserved for
... future
7 parameters
