3.4.10 Supported warnings
The diagnostic octets 22, 23 contain information on supported warnings.
DDLM_Slave_Diag
Octet
22
23
Bit
15 - 8
7 - 0
supported warnings
Bit
Definition
= 0
= 1
0
frequency warning
not supported
supported
1
temperature warning
not supported
supported
2
light control reserve warning
not supported
supported
3
CPU monitoring status warning
not supported
supported
4
maximum operating time exceeded
warning
not supported
supported
5
battery charging warning
not supported
supported
6
reference point warning
not supported
supported
7
Not yet
•
used
15
3.4.11 Profile version
Octets 24 and 25 of the diagnostic function provide the profile version of the Profibus-DP encoder
instrument which is implemented in the measuring instrument. The octets revision number and index are
combined.
Example:
Profile version:
1.40
Octet no.
24
25
Binary code:
00000001
01000000
Hex:
1
40
DDLM_Slave_Diag
Octet
24
25
Bit
15 - 8
7 - 0
Data
2
7
- 2
0
2
7
- 2
0
revision number
index
profile version
