45
3.2 Operating parameters
The Profibus-DP device is configured by means of the operating parameters. The values selected in the
configuration tool are stored in an EPROM or in a binary file and are transferred to the Profibus-DP slave
each time the system is started.
In the following table all parameters available are listed:
Parameters Data type Parameter
octet
number
Device class Details
Code Sequence bit 9 1 3.2.1
Class 2 functionality bit 9 2 3.2.2
Commissioning diagnostics bit 9 option 3.2.3
Scaling function control bit 9 2 3.2.4
Measuring units per revolution 32 bits without
sign
10 – 13 2 3.2.4
Total measuring range (units) 32 bits without
sign
14 – 17 2 3.2.4
Multi/Single separation bit 26 Special 3.2.5
Running indication bit 26 Special 3.2.6
Data_Exchange Alarm bit 26 Special 3.2.7
Control bit for limit switch function bit 26 Special 3.2.8
Limit switch minimum 32 bits without
sign
27 – 30 Special 3.2.9
Limit switch maximum 32 bits without
sign
31 – 34 Special 3.2.10
