Cybex 770T Treadmill - Handbuch (Seite 7)

Bedienungsanleitung für Cybex
7
Aufkleber „Warnung“
Abgenutzte oder beschädigte Aufkleber wie folgt bestellen oder ersetzen: Teile online unter
www.cybexintl.com , per Fax unter +1 508 533 5183 oder telefonisch beim Cybex-Kundendienst
unter 888-462-9239 (gebührenfrei in den USA) oder unter +1 508 533 4300 (von außerhalb der
USA) bestellen. Anbringungsort und Bestellnummer von Aufklebern können der Teileliste und der
Explosionsdarstellung auf der Cybex-Website unter www.cybexintl.com entnommen werden.
Warnaufkleber weisen auf Situationen mit Gefahrenpotenzial hin, das zum Tode oder zu schweren
Verletzungen führen kann, wenn die Vorsichtsmaßnahmen nicht eingehalten werden.
Sicherheitsaufkleber weisen auf eine potenziell gefährliche Situation hin, die zu leichten oder
mittelschweren Verletzungen führen kann, wenn sie nicht vermieden wird.
Die den Aufklebern folgenden Abbildungen zeigen, wo sie am Gerät angebracht sind.
