Treiber-Software für WINDOWS
29
Funktion Kurzreferenz
Position der Referenz-
marke ermitteln
BOOL IK220PositionRef (USHORT Axis, double* pData,
LONG*
pPeriod,
USHORT* pIntpol)
Position der steigenden
und fallenden Flanke der
Referenzmarke
ermitteln BOOL IK220PositionRef2 (USHORT Axis, double*pData,
LONG*
pPeriod,
USHORT* pIntpol)
Status IK 220 lesen BOOL IK220Status (USHORT Axis,
ULONG* pStatus)
Status der DLL-
Funktionen lesen BOOL IK220DllStatus (ULONG* pDLLStatus,
ULONG* pDLLInfo)
REF-Status lesen BOOL IK220RefStatus (USHORT Axis, LONG* pRef1,
LONG*
pRef2, LONG* pDiff,
LONG* pCode, USHORT* pFlag)
Signal-Status lesen BOOL IK220SignalStatus (USHORT Axis,
USHORT* Freq,
USHORT* pAmin,
USHORT* pAact,
USHORT* pAmax)
Angeglichene
Korrekturwerte lesen BOOL IK220GetCorrA (USHORT Axis,SHORT* pOfs0,
SHORT*
pOfs90, SHORT* Pha0,
SHORT* pPha90,SHORT* Sym0,
SHORT* pSym90,
USHORT* pFlag1,
USHORT* pFlag2)
Berechnete
Korrekturwerte lesen BOOL IK220GetCorrB (USHORT Axis,SHORT* pOfs0,
SHORT* pOfs90,SHORT* Pha0,
SHORT* Pha90,SHORT*pSym0,
SHORT* pSym90,
USHORT* pFlag1,
USHORT* pFlag2)
Korrekturwerte laden BOOL IK220LoadCorrA (USHORT Axis,SHORT Ofs0,
SHORT
Ofs90,SHORT Pha0,
SHORT Pha90,SHORT Sym0,
SHORT Sym90)
Oktanten-Status lesen BOOL IK220OctStatus (USHORT Axis,
USHORT*
pOct0,
USHORT* pOct1,
USHORT* pOct2,
USHORT* pOct3,
USHORT* pOct4,
USHORT* pOct5,
USHORT* pOct6,
USHORT* pOct7,
USHORT* pSamCnt)
