Hardware
72
Hardware
Specification of the PCI bus
The IK 220 can be installed in all PCs with PCI bus.
Specification PCI local bus Spec. Rev. 2.1
Size Approx. 100 * 190 mm
Connector PCI 5 V / 32-bit (2*60) connecting
element
PCI component PCI 9052 from PLX, target interface
(slave)
Current consumption +12 V: 22 mA
1)
-12 V: 22 mA
+5 V: 620 mA
Power consumption < 4 watts, without encoders
1)
Without current consumption of connected encoders
Identifier in component PCI9052:
Vendor ID = 0x10B5
Device ID = 0x9050
Subvendor ID = 0x10B5
Subdevice ID = 0x1172
The IK 220 can be unmistakably identified with these four
identifiers. The “Sub Device ID” is assigned exclusively to the
IK 220.
