Operating
Parameters
83
Param.
Number
For-
mat
Meaning
7
16 bits
0 to 12: Number of interpolation bits
Default value 12
The interpolation value (16-bit width, max. 12
significant bits, left-aligned) is rounded off to the
number of set bits.
8
16
bits
0: Compensation for position value off
1: Compensation for position value on
9
16
bits
0: Acquisition of compensation value off
1: Acquisition of compensation value on
10
16 bits
1 to 8: Number of measuring points per octant
within a signal period for calculation of
compensation values
Default value 1
11
16 bits
16 to 47: Time interval for timer
Default value 33 corresponds to 1 ms
3)
12
16 bits
Software divider for timer,
Default value 1
3)
13
16 bits
0 to 8191: Number of values per memory cycle
that are saved in the internal RAM
Default value 8191
14
16 bits
Bit 0=1 (integer 1): Enable the external latch L0
Bit 1=1 (integer 2): Enable internal time latch L0
Bit 2=1 (integer 4): Enable external latch L1
Default value 0
15
16 bits
1 to 48: SSI code length in bits
Default value 19
16
16 bits
0: No SSI parity
1: SSI parity (even)
2: SSI parity (even) with leading zeros
17
16 bits
0: SSI disable Gray-to-binary conversion
1: SSI enable Gray-to-binary conversion
18
16 bits
0 to 20: SSI no. of leading zeros
Default value 0
19
16 bits
0 to 20: SSI no. of trailing zeros
Default value 0
1)
Parameter is without function
2)
Depending on the connected encoder
(only even 16-bit values possible)
3)
See next page
