Dokumentierte Motoren – AL2xxx
Dokumentierte Motoren – AL2xxx
Linear Servomotor Geschwindigkeit
(maximal)
Spitzenkraft Dauerkraft
luftgekühlt Spitzenstrom
luftgekühlt
AL2003­0001­000y 10 m/s F
P
= 225 N F
ca
= 75 N I
ca
= 1,6 A
AL2006­0000­000y 4 m/s F
P
= 450 N F
ca
= 150 N I
ca
= 1,6 A
AL2006­0001­000y 10 m/s F
P
= 450 N F
ca
= 150N I
ca
= 3,3 A
AL2009­0000­000y 4 m/s F
P
= 675 N F
ca
= 225 N I
ca
= 3,6 A
AL2009­0001­000y 10 m/s F
P
= 675 N F
ca
= 225 N I
ca
= 6,8 A
AL2012­0000­000y 4 m/s F
P
= 900 N F
ca
= 300 N I
ca
= 3,3 A
AL2012­0001­000y 10 m/s F
P
= 900 N F
ca
= 300 N I
ca
= 6,5 A
AL2015­0000­000y 4 m/s F
P
= 1125 N F
ca
= 375 N I
ca
= 3,3 A
AL2015­0001­000y 10 m/s F
P
= 1125 N F
ca
= 375 N I
ca
= 8,2 A
AL2018­0000­000y 4 m/s F
P
= 1350 N F
ca
= 450 N I
ca
= 4,8 A
AL2018­0001­000y 10 m/s F
P
= 1350 N F
ca
= 450 N I
ca
= 10 A
AL2024­0000­000y 4 m/s F
P
= 1800 N F
ca
= 600 N I
ca
= 6,5 A
AL2024­0001­000y 10 m/s F
P
= 1800 N F
ca
= 600 N I
ca
= 13A
Linear Servomotor Geschwindigkeit
(maximal)
Spitzenkraft Dauerkraft
luftgekühlt Spitzenstrom
luftgekühlt
AL2403­0001­000y 8 m/s F
P
= 120 N F
ca
= 60 N I
ca
= 1,5 A
AL2406­0001­000y 8 m/s F
P
= 240 N F
ca
= 120 N I
ca
= 3,0 A
AL2412­0001­000y 8 m/s F
P
= 480 N F
ca
= 240 N I
ca
= 6,0 A
Linear Servomotor Geschwindigkeit
(maximal)
Spitzenkraft Dauerkraft
luftgekühlt Spitzenstrom
luftgekühlt
AL2812­0000­000y 2,5 m/s F
P
= 1800 N F
ca
= 760 N I
ca
= 4,1 A
AL2812­0001­000y 6,0 m/s F
P
= 1800 N F
ca
= 760 N I
ca
= 8,2 A
AL2815­0000­000y 2,5 m/s F
P
= 2250 N F
ca
= 950 N I
ca
= 4,2 A
AL2815­0001­000y 6,0 m/s F
P
= 2250 N F
ca
= 950 N I
ca
= 10,2 A
AL2830­0000­0000 2,5 m/s F
P
= 4500 N F
ca
= 1900 N I
ca
= 8,5 A
AL2830­0001­0000 6,0 m/s F
P
= 4500 N F
ca
= 1900 N I
ca
= 20 A
Wassergekühlt
Linear Servomotor Geschwindigkeit
(maximal)
Spitzenkraft Dauerkraft
wassergekühlt Spitzenstrom
wassergekühlt
AL2830­1000­0000 2,5 m/s F
P
= 4500 N F
cw
= 2000 N I
cw
= 8,9 A
AL2830­1001­0000 6,0 m/s F
P
= 4500 N F
cw
= 2000 N I
cw
= 21,5 A
AL2845­1000­0000 2,5 m/s F
P
= 6750 N F
cw
= 3000 N I
cw
= 13,4 A
AL2845­1001­0000 6,0 m/s F
P
= 6750 N F
cw
= 3000 N I
cw
= 32,3 A
