9469375991 Rev A 99
DGC-2020HD Modbus ™ Protokoll Standardregistertabelle
Name Beschreibung Gruppe Register Typ Bytes R/W Einheit Bereich
AEM 2 Externer
Analogausgang 3 Strom Minimum GG 7788 Float 4 R W Milliamp 4 - 20
AEM 2 Externer
Analogausgang 3 Strom Maximum GG 7790 Float 4 R W Milliamp 4 - 20
AEM 2 Externer
Analogausgang 3 Spannung Minimum GG 7792 Float 4 R W Volt 0 - 10
AEM 2 Externer
Analogausgang 3 Spannung Maximum GG 7794 Float 4 R W Volt 0 - 10
AEM 2 Externer
Analogausgang 3
Alarmkonfiguration GG 7796 Uint32 4 R W n.z. Nur Status=0
Voralarm=1
Alarm=2
AEM 2 Externer
Analogausgang 4 Parameterauswahl GG 7798 Int32 4 R W n.z. Kein Parameter=0
Öldruck=1
Kühlmitteltemp.=2
Batteriespannung=3
RPM=4
Kraftstoffpegel=5
Gen Hz=6
Gen VAB=7
Gen VBC=8
Gen VCA=9
Gen Vavg LL=10
Gen VAN=11
Gen VBN=12
Gen VCN=13
Gen Vavg LN=14
Bus 1 Hz=15
Bus 1 VAB=16
Bus 1 VBC=17
Bus 1 VCA=18
Bus 1 Vavg LL=19
Bus 1 VA=20
Bus 1 VB=21
Bus 1 VC=22
Bus 1 Vavg LN=23
Bus 2 Hz=24
Bus 2 VAB=25
Bus 2 VBC=26
Bus 2 VCA=27
Bus 2 Vavg LL=28
Bus 2 VAN=29
Bus 2 VBN=30
Bus 2 VCN=31
Bus 2 Vavg LN=32
Gen PF=33
Bus 1 PF=34
Bus 2 PF=35
Gen Pos kWh=36
Gen Neg kWh=37
Bus 1 Pos kWh=38
Bus 1 Neg kWh=39
Bus 2 Pos kWh=40
Bus 2 Neg kWh=41
Gen IA=42
Gen IB=43
Gen IC=44
Gen I Avg=45
Bus 1 IA=46
Bus 1 IB=47
Bus 1 IC=48
Bus 1 Iavg=49
Bus 2 IAN=50
Bus 2 IBN=51
Bus 2 ICN=52
Bus 2 Iavg=53
IG=54
I Aux=55
Gen kW A=56
Gen kW B=57
Gen kW C=58
Gen kW gesamt=59
Bus 1 kW A=60
Bus 1 kW B=61
Bus 1 kW C=62
Bus 1 kW gesamt=63
Bus 2 kW A=64
Bus 2 kW B=65
Bus 2 kW C=66
Bus 2 kW gesamt=67
Gen kVA A=68
Gen kVA B=69
Gen kVA C=70
