Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 215
9469375991 Rev A
209
DGC-2020HD Modbus
™ Protokoll
Standardregistertabelle
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-6
Kurvenindex
SG0 1P 24326
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-6
Richtung
SG0 1P 24328
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-6
Sofortiges Zurücksetzen
verwenden
SG0 1P 24330
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-6
Konstante TD
SG0 1P 24332
Float
4
R W n.z.
0 - 9.9
51-6
Konstante A
SG0 1P 24334
Float
4
R W n.z.
0 - 600
51-6
Konstante B
SG0 1P 24336
Float
4
R W n.z.
0 - 25
51-6
Konstante C
SG0 1P 24338
Float
4
R W n.z.
0 - 1
51-6
Konstante N
SG0 1P 24340
Float
4
R W n.z.
0.5 - 2.5
51-6
Konstante R
SG0 1P 24342
Float
4
R W n.z.
0 - 30
51-6
Spannungsbegrenzung Sollwert SG0 1P 24344
Float
4
R W Volt
30 - 250
51-6
Spannungsbegrenzung Modus
SG0 1P 24346
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-6
Alarmkonfiguration
SG0 1P 24348
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-6
Niedrige Leitung Skalierung
SG0 1P 24350
Float
4
R W n.z.
0,001 - 3
51-6
Spannungsbegrenzung Quelle
SG0 1P 24352
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-6
Konstante Q
SG0 1P 24354
Float
4
R W n.z.
0.1 - 10
51-6
Modus
SG0 3P 24356
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-6
Quelle
SG0 3P 24358
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-6
Abgriff
SG0 3P 24360
Float
4
R W Amp
0.9 - 7.75
51-6
Kurvenindex
SG0 3P 24362
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-6
Richtung
SG0 3P 24364
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-6
Sofortiges Zurücksetzen
verwenden
SG0 3P 24366
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-6
Konstante TD
SG0 3P 24368
Float
4
R W n.z.
0 - 9.9
