DGC-2020HD Modbus
™ Protokoll
Standardregistertabelle
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-2
Konstante A
SG2 3P 23362
Float
4
R W n.z.
0 - 600
51-2
Konstante B
SG2 3P 23364
Float
4
R W n.z.
0 - 25
51-2
Konstante C
SG2 3P 23366
Float
4
R W n.z.
0 - 1
51-2
Konstante N
SG2 3P 23368
Float
4
R W n.z.
0.5 - 2.5
51-2
Konstante R
SG2 3P 23370
Float
4
R W n.z.
0 - 30
51-2
Spannungsbegrenzung Sollwert SG2 3P 23372
Float
4
R W Volt
30 - 250
51-2
Spannungsbegrenzung Modus
SG2 3P 23374
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-2
Alarmkonfiguration
SG2 3P 23376
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-2
Niedrige Leitung Skalierung
SG2 3P 23378
Float
4
R W n.z.
0,001 - 3
51-2
Spannungsbegrenzung Quelle
SG2 3P 23380
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-2
Konstante Q
SG2 3P 23382
Float
4
R W n.z.
0.1 - 10
51-2
Modus
SG3 1P 23384
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-2
Quelle
SG3 1P 23386
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-2
Abgriff
SG3 1P 23388
Float
4
R W Amp
0.9 - 7.75
51-2
Kurvenindex
SG3 1P 23390
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-2
Richtung
SG3 1P 23392
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-2
Sofortiges Zurücksetzen
verwenden
SG3 1P 23394
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-2
Konstante TD
SG3 1P 23396
Float
4
R W n.z.
0 - 9.9
51-2
Konstante A
SG3 1P 23398
Float
4
R W n.z.
0 - 600
51-2
Konstante B
SG3 1P 23400
Float
4
R W n.z.
0 - 25
51-2
Konstante C
SG3 1P 23402
Float
4
R W n.z.
0 - 1
51-2
Konstante N
SG3 1P 23404
Float
4
R W n.z.
0.5 - 2.5
51-2
Konstante R
SG3 1P 23406
Float
4
R W n.z.
0 - 30
51-2
Spannungsbegrenzung Sollwert SG3 1P 23408
Float
4
R W Volt
30 - 250
51-2
Spannungsbegrenzung Modus
SG3 1P 23410
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-2
Alarmkonfiguration
SG3 1P 23412
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-2
Niedrige Leitung Skalierung
SG3 1P 23414
Float
4
R W n.z.
0,001 - 3
51-2
Spannungsbegrenzung Quelle
SG3 1P 23416
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-2
Konstante Q
SG3 1P 23418
Float
4
R W n.z.
0.1 - 10
