Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 208
202
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-4
Modus
SG3 3P 23996
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-4
Quelle
SG3 3P 23998
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-4
Abgriff
SG3 3P 24000
Float
4
R W Amp
0.9 - 7.75
51-4
Kurvenindex
SG3 3P 24002
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-4
Richtung
SG3 3P 24004
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-4
Sofortiges Zurücksetzen
verwenden
SG3 3P 24006
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-4
Konstante TD
SG3 3P 24008
Float
4
R W n.z.
0 - 9.9
51-4
Konstante A
SG3 3P 24010
Float
4
R W n.z.
0 - 600
51-4
Konstante B
SG3 3P 24012
Float
4
R W n.z.
0 - 25
51-4
Konstante C
SG3 3P 24014
Float
4
R W n.z.
0 - 1
51-4
Konstante N
SG3 3P 24016
Float
4
R W n.z.
0.5 - 2.5
51-4
Konstante R
SG3 3P 24018
Float
4
R W n.z.
0 - 30
51-4
Spannungsbegrenzung Sollwert SG3 3P 24020
Float
4
R W Volt
30 - 250
51-4
Spannungsbegrenzung Modus
SG3 3P 24022
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-4
Alarmkonfiguration
SG3 3P 24024
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-4
Niedrige Leitung Skalierung
SG3 3P 24026
Float
4
R W n.z.
0,001 - 3
51-4
Spannungsbegrenzung Quelle
SG3 3P 24028
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-4
Konstante Q
SG3 3P 24030
Float
4
R W n.z.
0.1 - 10
51-5
Modus
SG0 1P 24032
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-5
Quelle
SG0 1P 24034
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-5
Abgriff
SG0 1P 24036
Float
4
R W Amp
0.9 - 7.75
