Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 193
9469375991 Rev A
187
DGC-2020HD Modbus
™ Protokoll
Standardregistertabelle
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-2
Modus
SG1 3P 23276
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-2
Quelle
SG1 3P 23278
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-2
Abgriff
SG1 3P 23280
Float
4
R W Amp
0.9 - 7.75
51-2
Kurvenindex
SG1 3P 23282
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-2
Richtung
SG1 3P 23284
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-2
Sofortiges Zurücksetzen
verwenden
SG1 3P 23286
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-2
Konstante TD
SG1 3P 23288
Float
4
R W n.z.
0 - 9.9
51-2
Konstante A
SG1 3P 23290
Float
4
R W n.z.
0 - 600
51-2
Konstante B
SG1 3P 23292
Float
4
R W n.z.
0 - 25
51-2
Konstante C
SG1 3P 23294
Float
4
R W n.z.
0 - 1
51-2
Konstante N
SG1 3P 23296
Float
4
R W n.z.
0.5 - 2.5
51-2
Konstante R
SG1 3P 23298
Float
4
R W n.z.
0 - 30
51-2
Spannungsbegrenzung Sollwert SG1 3P 23300
Float
4
R W Volt
30 - 250
51-2
Spannungsbegrenzung Modus
SG1 3P 23302
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-2
Alarmkonfiguration
SG1 3P 23304
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-2
Niedrige Leitung Skalierung
SG1 3P 23306
Float
4
R W n.z.
0,001 - 3
51-2
Spannungsbegrenzung Quelle
SG1 3P 23308
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-2
Konstante Q
SG1 3P 23310
Float
4
R W n.z.
0.1 - 10
51-2
Modus
SG2 1P 23312
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-2
Quelle
SG2 1P 23314
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-2
Abgriff
SG2 1P 23316
Float
4
R W Amp
0.9 - 7.75
