Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 206
200
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-4
Kurvenindex
SG2 1P 23894
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-4
Richtung
SG2 1P 23896
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-4
Sofortiges Zurücksetzen
verwenden
SG2 1P 23898
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-4
Konstante TD
SG2 1P 23900
Float
4
R W n.z.
0 - 9.9
51-4
Konstante A
SG2 1P 23902
Float
4
R W n.z.
0 - 600
51-4
Konstante B
SG2 1P 23904
Float
4
R W n.z.
0 - 25
51-4
Konstante C
SG2 1P 23906
Float
4
R W n.z.
0 - 1
51-4
Konstante N
SG2 1P 23908
Float
4
R W n.z.
0.5 - 2.5
51-4
Konstante R
SG2 1P 23910
Float
4
R W n.z.
0 - 30
51-4
Spannungsbegrenzung Sollwert SG2 1P 23912
Float
4
R W Volt
30 - 250
51-4
Spannungsbegrenzung Modus
SG2 1P 23914
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-4
Alarmkonfiguration
SG2 1P 23916
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-4
Niedrige Leitung Skalierung
SG2 1P 23918
Float
4
R W n.z.
0,001 - 3
51-4
Spannungsbegrenzung Quelle
SG2 1P 23920
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-4
Konstante Q
SG2 1P 23922
Float
4
R W n.z.
0.1 - 10
51-4
Modus
SG2 3P 23924
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-4
Quelle
SG2 3P 23926
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-4
Abgriff
SG2 3P 23928
Float
4
R W Amp
0.9 - 7.75
51-4
Kurvenindex
SG2 3P 23930
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-4
Richtung
SG2 3P 23932
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-4
Sofortiges Zurücksetzen
verwenden
SG2 3P 23934
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-4
Konstante TD
SG2 3P 23936
Float
4
R W n.z.
0 - 9.9
