Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 142
136
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
Bus 2 Strommessung Mag I1
GG
10214
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Mag I2
GG
10216
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Mag 3I0
GG
10218
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Mag IAVG
GG
10220
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Pri
IA
GG
10222
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Pri
IB
GG
10224
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Pri
IC
GG
10226
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Pri
I1
GG
10228
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Pri
I2
GG
10230
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Pri
3I0
GG
10232
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung Pri
IAVG
GG
10234
Float
4
R
Amp
0 - 2000000000
Bus 2 Strommessung
Winkel
IA
GG
10236
Float
4
R
Grad
0 - 360
Bus 2 Strommessung
Winkel
IB
GG
10238
Float
4
R
Grad
0 - 360
Bus 2 Strommessung
Winkel
IC
GG
10240
Float
4
R
Grad
0 - 360
Icc Strommessung Mag 1
IX
GG
10242
Float
4
R
Amp
0 - 2000000000
Icc Strommessung Pri 1
IX
GG
10244
Float
4
R
Amp
0 - 2000000000
Icc Strommessung Winkel
1
IX
GG
10246
Float
4
R
Grad
0 - 360
Leistungsmessung
Watt A Primärseite
Mittelwert
GG
10248
Float
4
R
Watt
0 - 3.00E+14
Leistungsmessung
Watt B Primärseite
Mittelwert
GG
10250
Float
4
R
Watt
0 - 3.00E+14
Leistungsmessung
Watt C Primärseite
Mittelwert
GG
10252
Float
4
R
Watt
0 - 3.00E+14
Leistungsmessung
gesamt Watts
Primärseite Mittelwert
GG
10254
Float
4
R
Watt
0 - 3.00E+14
Leistungsmessung
VAr A Primärseite
Mittelwert
GG
10256
Float
4
R
VAr
0 - 3.00E+14
Leistungsmessung
VAr B Primärseite
Mittelwert
GG
10258
Float
4
R
VAr
0 - 3.00E+14
Leistungsmessung
VAr C Primärseite
Mittelwert
GG
10260
Float
4
R
VAr
0 - 3.00E+14
Leistungsmessung
gesamt vars Primärseite
Mittelwert
GG
10262
Float
4
R
VAr
0 - 3.00E+14
Leistungsmessung
S A Primärseite
Mittelwert
GG
10264
Float
4
R
VA
0 - 3.00E+14
Leistungsmessung
S B Primärseite
Mittelwert
GG
10266
Float
4
R
VA
0 - 3.00E+14
Leistungsmessung
S C Primärseite
Mittelwert
GG
10268
Float
4
R
VA
0 - 3.00E+14
Leistungsmessung
gesamt S Primärseite
Mittelwert
GG
10270
Float
4
R
VA
0 - 3.00E+14
Leistungsmessung
PF A Primärseite
Mittelwert
GG
10272
Float
4
R
Leistungsfaktor -1 - 1
Leistungsmessung
PF B Primärseite
Mittelwert
GG
10274
Float
4
R
Leistungsfaktor -1 - 1
Leistungsmessung
PF C Primärseite
Mittelwert
GG
10276
Float
4
R
Leistungsfaktor -1 - 1
Leistungsmessung
gesamt PF Primärseite
Mittelwert
GG
10278
Float
4
R
Leistungsfaktor -1 - 1
Leistungsmessung 2
Watt A Primärseite
Mittelwert
GG
10280
Float
4
R
Watt
0 - 3.00E+14
Leistungsmessung 2
Watt B Primärseite
Mittelwert
GG
10282
Float
4
R
Watt
0 - 3.00E+14
Leistungsmessung 2
Watt C Primärseite
Mittelwert
GG
10284
Float
4
R
Watt
0 - 3.00E+14
Leistungsmessung 2
gesamt Watts
Primärseite Mittelwert
GG
10286
Float
4
R
Watt
0 - 3.00E+14
Leistungsmessung 2
VAr A Primärseite
Mittelwert
GG
10288
Float
4
R
VAr
0 - 3.00E+14
Leistungsmessung 2
VAr B Primärseite
Mittelwert
GG
10290
Float
4
R
VAr
0 - 3.00E+14
Leistungsmessung 2
VAr C Primärseite
Mittelwert
GG
10292
Float
4
R
VAr
0 - 3.00E+14
Leistungsmessung 2
gesamt vars Primärseite
Mittelwert
GG
10294
Float
4
R
VAr
0 - 3.00E+14
Leistungsmessung 2
S A Primärseite
Mittelwert
GG
10296
Float
4
R
VA
0 - 3.00E+14
Leistungsmessung 2
S B Primärseite
Mittelwert
GG
10298
Float
4
R
VA
0 - 3.00E+14
Leistungsmessung 2
S C Primärseite
Mittelwert
GG
10300
Float
4
R
VA
0 - 3.00E+14
Leistungsmessung 2
gesamt S Primärseite
Mittelwert
GG
10302
Float
4
R
VA
0 - 3.00E+14
