Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 205
9469375991 Rev A
199
DGC-2020HD Modbus
™ Protokoll
Standardregistertabelle
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-4
Modus
SG1 3P 23852
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-4
Quelle
SG1 3P 23854
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-4
Abgriff
SG1 3P 23856
Float
4
R W Amp
0.9 - 7.75
51-4
Kurvenindex
SG1 3P 23858
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-4
Richtung
SG1 3P 23860
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-4
Sofortiges Zurücksetzen
verwenden
SG1 3P 23862
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-4
Konstante TD
SG1 3P 23864
Float
4
R W n.z.
0 - 9.9
51-4
Konstante A
SG1 3P 23866
Float
4
R W n.z.
0 - 600
51-4
Konstante B
SG1 3P 23868
Float
4
R W n.z.
0 - 25
51-4
Konstante C
SG1 3P 23870
Float
4
R W n.z.
0 - 1
51-4
Konstante N
SG1 3P 23872
Float
4
R W n.z.
0.5 - 2.5
51-4
Konstante R
SG1 3P 23874
Float
4
R W n.z.
0 - 30
51-4
Spannungsbegrenzung Sollwert SG1 3P 23876
Float
4
R W Volt
30 - 250
51-4
Spannungsbegrenzung Modus
SG1 3P 23878
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-4
Alarmkonfiguration
SG1 3P 23880
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-4
Niedrige Leitung Skalierung
SG1 3P 23882
Float
4
R W n.z.
0,001 - 3
51-4
Spannungsbegrenzung Quelle
SG1 3P 23884
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-4
Konstante Q
SG1 3P 23886
Float
4
R W n.z.
0.1 - 10
51-4
Modus
SG2 1P 23888
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-4
Quelle
SG2 1P 23890
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-4
Abgriff
SG2 1P 23892
Float
4
R W Amp
0.9 - 7.75
