DGC-2020HD Modbus
™ Protokoll
Standardregistertabelle
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-1
Konstante A
SG2 3P 23074
Float
4
R W n.z.
0 - 600
51-1
Konstante B
SG2 3P 23076
Float
4
R W n.z.
0 - 25
51-1
Konstante C
SG2 3P 23078
Float
4
R W n.z.
0 - 1
51-1
Konstante N
SG2 3P 23080
Float
4
R W n.z.
0.5 - 2.5
51-1
Konstante R
SG2 3P 23082
Float
4
R W n.z.
0 - 30
51-1
Spannungsbegrenzung Sollwert SG2 3P 23084
Float
4
R W Volt
30 - 250
51-1
Spannungsbegrenzung Modus
SG2 3P 23086
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-1
Alarmkonfiguration
SG2 3P 23088
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-1
Niedrige Leitung Skalierung
SG2 3P 23090
Float
4
R W n.z.
0,001 - 3
51-1
Spannungsbegrenzung Quelle
SG2 3P 23092
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-1
Konstante Q
SG2 3P 23094
Float
4
R W n.z.
0.1 - 10
51-1
Modus
SG3 1P 23096
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-1
Quelle
SG3 1P 23098
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-1
Abgriff
SG3 1P 23100
Float
4
R W Amp
0.9 - 7.75
51-1
Kurvenindex
SG3 1P 23102
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-1
Richtung
SG3 1P 23104
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-1
Sofortiges Zurücksetzen
verwenden
SG3 1P 23106
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-1
Konstante TD
SG3 1P 23108
Float
4
R W n.z.
0 - 9.9
51-1
Konstante A
SG3 1P 23110
Float
4
R W n.z.
0 - 600
51-1
Konstante B
SG3 1P 23112
Float
4
R W n.z.
0 - 25
51-1
Konstante C
SG3 1P 23114
Float
4
R W n.z.
0 - 1
51-1
Konstante N
SG3 1P 23116
Float
4
R W n.z.
0.5 - 2.5
51-1
Konstante R
SG3 1P 23118
Float
4
R W n.z.
0 - 30
51-1
Spannungsbegrenzung Sollwert SG3 1P 23120
Float
4
R W Volt
30 - 250
51-1
Spannungsbegrenzung Modus
SG3 1P 23122
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-1
Alarmkonfiguration
SG3 1P 23124
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-1
Niedrige Leitung Skalierung
SG3 1P 23126
Float
4
R W n.z.
0,001 - 3
51-1
Spannungsbegrenzung Quelle
SG3 1P 23128
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-1
Konstante Q
SG3 1P 23130
Float
4
R W n.z.
0.1 - 10
