Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 212
206
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-5
Kurvenindex
SG2 1P 24182
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-5
Richtung
SG2 1P 24184
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-5
Sofortiges Zurücksetzen
verwenden
SG2 1P 24186
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-5
Konstante TD
SG2 1P 24188
Float
4
R W n.z.
0 - 9.9
51-5
Konstante A
SG2 1P 24190
Float
4
R W n.z.
0 - 600
51-5
Konstante B
SG2 1P 24192
Float
4
R W n.z.
0 - 25
51-5
Konstante C
SG2 1P 24194
Float
4
R W n.z.
0 - 1
51-5
Konstante N
SG2 1P 24196
Float
4
R W n.z.
0.5 - 2.5
51-5
Konstante R
SG2 1P 24198
Float
4
R W n.z.
0 - 30
51-5
Spannungsbegrenzung Sollwert SG2 1P 24200
Float
4
R W Volt
30 - 250
51-5
Spannungsbegrenzung Modus
SG2 1P 24202
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-5
Alarmkonfiguration
SG2 1P 24204
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-5
Niedrige Leitung Skalierung
SG2 1P 24206
Float
4
R W n.z.
0,001 - 3
51-5
Spannungsbegrenzung Quelle
SG2 1P 24208
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-5
Konstante Q
SG2 1P 24210
Float
4
R W n.z.
0.1 - 10
51-5
Modus
SG2 3P 24212
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-5
Quelle
SG2 3P 24214
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-5
Abgriff
SG2 3P 24216
Float
4
R W Amp
0.9 - 7.75
51-5
Kurvenindex
SG2 3P 24218
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-5
Richtung
SG2 3P 24220
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-5
Sofortiges Zurücksetzen
verwenden
SG2 3P 24222
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-5
Konstante TD
SG2 3P 24224
Float
4
R W n.z.
0 - 9.9
