Basler Electric DGC-2020HD Modbus Protocol Benutzerhandbuch
Seite 216
210
9469375991 Rev A
Standardregistertabelle
DGC-2020HD Modbus
™ Protokoll
Name
Beschreibung
Gruppe Register
Typ
Bytes R/W
Einheit
Bereich
51-6
Konstante A
SG0 3P 24370
Float
4
R W n.z.
0 - 600
51-6
Konstante B
SG0 3P 24372
Float
4
R W n.z.
0 - 25
51-6
Konstante C
SG0 3P 24374
Float
4
R W n.z.
0 - 1
51-6
Konstante N
SG0 3P 24376
Float
4
R W n.z.
0.5 - 2.5
51-6
Konstante R
SG0 3P 24378
Float
4
R W n.z.
0 - 30
51-6
Spannungsbegrenzung Sollwert SG0 3P 24380
Float
4
R W Volt
30 - 250
51-6
Spannungsbegrenzung Modus
SG0 3P 24382
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-6
Alarmkonfiguration
SG0 3P 24384
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-6
Niedrige Leitung Skalierung
SG0 3P 24386
Float
4
R W n.z.
0,001 - 3
51-6
Spannungsbegrenzung Quelle
SG0 3P 24388
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-6
Konstante Q
SG0 3P 24390
Float
4
R W n.z.
0.1 - 10
51-6
Modus
SG1 1P 24392
Uint32 4
R W n.z.
Deaktiviert=0
IA=1
IB=2
IC=3
Imax=4
3I0=5
I2=6
IG=7
I1=8
51-6
Quelle
SG1 1P 24394
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-6
Abgriff
SG1 1P 24396
Float
4
R W Amp
0.9 - 7.75
51-6
Kurvenindex
SG1 1P 24398
Uint32 4
R W n.z.
S1=0
S2=1
L1=2
L2=3
D=4
M=5
I1=6
I2=7
V1=8
V2=9
E1=10
E2=11
A=12
B=13
C=14
G=15
F=16
46=17
P=18
51-6
Richtung
SG1 1P 24400
Uint32 4
R W n.z.
mitläufig=0
gegenläufig=1
nicht Richtungsgebunden=2
51-6
Sofortiges Zurücksetzen
verwenden
SG1 1P 24402
Uint32 4
R W n.z.
Integriert=0
Sofort=1
51-6
Konstante TD
SG1 1P 24404
Float
4
R W n.z.
0 - 9.9
51-6
Konstante A
SG1 1P 24406
Float
4
R W n.z.
0 - 600
51-6
Konstante B
SG1 1P 24408
Float
4
R W n.z.
0 - 25
51-6
Konstante C
SG1 1P 24410
Float
4
R W n.z.
0 - 1
51-6
Konstante N
SG1 1P 24412
Float
4
R W n.z.
0.5 - 2.5
51-6
Konstante R
SG1 1P 24414
Float
4
R W n.z.
0 - 30
51-6
Spannungsbegrenzung Sollwert SG1 1P 24416
Float
4
R W Volt
30 - 250
51-6
Spannungsbegrenzung Modus
SG1 1P 24418
Uint32 4
R W n.z.
Deaktiviert=0
Steuerung=1
Begrenzung=2
51-6
Alarmkonfiguration
SG1 1P 24420
Uint32 4
R W n.z.
Nur Status=0
Voralarm=1
Alarm=2
51-6
Niedrige Leitung Skalierung
SG1 1P 24422
Float
4
R W n.z.
0,001 - 3
51-6
Spannungsbegrenzung Quelle
SG1 1P 24424
Uint32 4
R W n.z.
Gen=0
Bus 1=1
Bus 2=2
51-6
Konstante Q
SG1 1P 24426
Float
4
R W n.z.
0.1 - 10
